Inta Shower Panel Stainless Steel With Time Flow Control & Tmv3 Mixing Valve – Sp9200cp

Inta Shower Panel Stainless Steel With Time Flow Control & Tmv3 Mixing Valve – Sp9200cp

• Colour: Stainless Steel
• Guarantee: 5 Years
• Inlet Connection: 15mm Compression
• Minimum Running Pressure: 0.5 Bar
• Temperature Control: Thermostatic

The Intatec range of vandal resistant shower panels is designed for use within commercial applications such as schools, prisons, sports centres etc. The robust construction and high quality of materials used makes it ideal for use in hostile or high use environments.

High grade stainless steel

TMV3 Approved

WRAs Approved timed flow control

Concealed fixings

Pre-plumbed fittings

Fully serviceable panel

Non thermostatic and Infra red options available

Vandal resistant

Technical Specifications

Inlet connections: 15mm compression
Max inlet temperature: 65°C
Max operating pressure static: 10 bar
Max pressure inlet differential: 5:1
Min operating pressure dynamic: 0.5 bar
Min temp differential to achieve failsafe: 10°C
Temperature adjustment range: 30°C – 50°C
Temperature stability: ± 2°C
