Product Description

SCALA2 is a fully integrated water booster pump providing perfect water
pressure in all taps at all times – even with multiple taps and showers
running at the same time. It packs pump, motor, tank, sensor, drive and
non-return valve into one compact unit. With its intelligent pump
control, SCALA2 automatically adjusts performance to both inlet pressure
and water consumption in the home. Thanks to a water-cooled motor,
SCALA2 even offers one of the lowest noise levels of any booster on the
market.

Product Specification

Specifications
Product name	SCALA2 3-45 A
Product No	98562865
EAN number	5711497234247
Technical
Rated flow	3 m³/h
Rated head	27 m
Head max	45 m
Primary shaft seal	CARBON/CERAMIC
Approvals on nameplate	CE,VDE
Approvals for drinking water	WRAS,ACS
Curve tolerance	ISO9906:2012 3B
Model	A
Materials
Pump housing	NORYL FE1630PW PPE+PS-GS30
Impeller	NORYL FE1630PW PPE+PS-GS30
Material code	A
Installation
Range of ambient temperature	0 .. 55 °C
Maximum operating pressure	10 bar
Maximum permissible inlet pressure	6 bar
Pipe connection	G 1 Composite
Liquid
Pumped liquid	Water
Liquid temperature range	0 .. 45 °C
Liquid temperature during operation	20 °C
Density	998.2 kg/m³
Electrical data
Power input – P1	550 W
Mains frequency	50 Hz
Rated voltage	1 x 200-240 V
Rated current	2.8 A
Enclosure class (IEC 34-5)	IPX4D
Insulation class (IEC 85)	F
Length of cable	2 m
Power plug	NO PLUG
Others
Net weight	9.5 kg
Gross weight	11.8 kg
Shipping volume	0.044 m³
Storage temperature range	-40 .. 70 °C
